Lift Trucks Mast System Testing & Adjusting25
Mast Mounting Group Adjustment
DETAIL A
2,3
6
5
1
4
1. Apply clean grease to surface of bearing (6)
before pin (5) installation.
2. Install block (4) with bolt (2) and washer (3).
Tighten the bolt to a torque of 600 L 70 N¥m (440
L 50 lb¥ft).
3. Apply grease through fitting (1).
