3.3.29. Vibration damper and pulley
•
Install the vibration damper on the
crankshaft pulley.
•
Install the crankshaft pulley assembly
on the crankshaft, then tighten the
bolts and thrust washers.
3.3.30. Water pump
•
Mount a new O-ring.
•
Install the water pump drive pinion
over the air compressor spline.
•
Connect water pipes and by-pass
pipe to the water pump.
•
Connect a water pipe to the expan-
sion tank.
3.3.31. Exhaust manifold
•
Install the exhaust manifold gasket
over the stud bolts by aligning the
gasket with the exhaust port on the
cylinder head so that the face and
back of the gasket can be positioned
correctly.
•
Semi-assemble the exhaust mani-
fold and install the heat resisting
plate.
3.3.32.Turbocharger
•
Fit a new gasket over the stud bolts
of the exhaust manifold before tight-
ening those turbocharger fixing
bolts.
•
Install the oil supply pipe and return
pipe.
- 94 -
REASSEMBLY
Torque 13.4 kg
.
m
