- 95 -
REASSEMBLY
3.3.33. Air pipe
•
Semi-assemble the bracket to the
intake pipe, connect a rubber hose
between the turbocharger and intake
pipe using the clamps, then assem-
ble the bracket completely.
3.3.34. Starter
•
Assemble the starter in position on
the flywheel housing.
3.3.35. Intake manifold
•
Fit a gasket on the intake manifold
before assembling the intake mani-
fold.
•
Mount the air heater gasket on the
intake manifold, then assemble the
air heater with the intake manifold.
•
Connect the air hoses to the boost
compensator mounted on the fuel
injection pump.
