LF45/55 series Removal and installation
SEATS
4-7
4.9 REMOVAL AND INSTALLATION, COVER PANEL ON NON-CONTROL SIDE
Removing cover panel on non-control side
1. Remove the seat assembly.
2. Remove the seat squab.
3. Remove the front cover panel.
4. Remove the rear cover panel.
5. Remove the attachment screw on the inside
of the backrest hinge bracket.
6. Remove the attachment screws on the seat
frame.
7. Remove the attachment screw of the seat
belt lock.
8. Remove the seat belt lock.
9. Remove the cover panel.
Installing cover panel on non-control side
1. Fit the cover panel to the seat frame and
the backrest hinge bracket using the
attachment screws.
2. Fit the seat belt lock using the attachment
screw.
3. Fit the front cover panel using the
attachment screws.
4. Fit the rear cover panel using the
attachment plugs.
5. Fit the seat squab.
6. Install the seat assembly.
