1) Install deflector, ensuring that both red marks are aligned with the
deflector holes – see Figure 8.9.4.
NOTE
Position deflectors as indicated on label, according to future
position of intermediate seat, in order to optimize cabin
cooling.
NOTE
If seats are installed facing flight direction (frontwards), the
left-side seat must be installed on the right and the right-side
seat on the left in order to have the armrest on aisle side.
2) Pull backrest bottom upholstery to remove it.
3) Clear the carpet from seat area to facilitate moving in rails.
4) Position the
seat and put lock near the color mark made on rail
bottom on aisle side.
NOTE
The color mark in the rail is aligned with red marks.
5) Open the floor hatch and remove the clips from the holders
located under the
floor panel and connect both the heating
system and headset plug harnesses. Clip the connectors on the
holders located on the seat structure.
6) Pull up locking handle , insert pads into rail apertures and then,
move the seat so that lock is in front of the color mark.
7) Release locking handle to lock the seat.
WARNING
Verify that lock and all pads are engaged and locked into
rails, trying to move seat forward and backward.
8) Install backrest bottom upholstery.
NOTE
Adjust it properly; make sure not to obstruct deflector outlet.
9) Slide properly the carpet under the seat.
Section 8
Handling, Servicing and Maintenance
Pilot's Information Manual
PIM TBM 960 - Edition 0
Rev. 01
Page 8.9.4
PIM - DO NOT USE FOR FLIGHT OPERATIONS
