User's Manual
156
on the alarm device, the alarm information will be uploaded to the Device, and then the Device
outputs the local alarms in the way that you configure in this section.
Procedure
Step 1 Select
Main Menu
>
ALARM
>
Alarm-in Port
>
Local
.
Figure 5-112 Local
Step 2 Configure the settings for the local alarms.
Table 5-35 Local alarm settings
Parameter Description
Alarm-in Port Select the channel number.
Alarm Name Enter the customized alarm name.
Enable Enable or disable the local alarm function.
Device Type
In the
Device Type
list, select
NO
or select
NC
as the voltage output
type.
Schedule
Click
Setting
to configure the parameters.
Define a period during which the motion detection is active. For
details, see "5.10.4.1 Configuring Motion Detection Settings".
Anti-Dither
Configure the time period from end of event detection to the stop
of alarm.
