Parameter Description
Compression
Select the encoding mode.
●
H.265: Main prole encoding. This setting is recommended.
●
H.264H: High prole encoding. Low bit stream with high denition.
●
H.264: Main prole encoding.
●
H.264B: Baseline prole encoding. This mode requires higher bit
stream compared with other modes for the same denition.
Resolution
Select resolution for the video.
The maximum video resolution might be dierent depending on your
device model.
Frame Rate (FPS)
Congure the frames per second for the video. The higher the value is,
the clearer and smoother the image will become. Frame rate changes
along with the resolution.
Generally, in PAL format, you can select the value from 1 through 25; in
NTSC format, you can select the value from 1 through 30. However, the
actual range of frame rate that you can select depends on the capability
of the Device.
Bit Rate Type
●
CBR (constant bit rate): The bit rate changes slightly around the
dened value. We recommended selecting CBR when there might
be only small changes in the monitoring environment.
●
VBR (variable bit rate): The bit rate changes with monitoring scenes.
Select variable stream when there might be big changes in the
monitoring environment.
●
ABR (average bit rate): When selecting ABR, you need to congure
Max Bit Rate and ABR.
The connected camera needs to support the average bit rare.
Quality
The bigger the value is, the better the image will become.
This parameter is available if you select VBR as Bit Rate Type.
I Frame Interval The interval between two reference frames.
Bit Rate (Kb/S)
●
Main stream: The higher the value, the better the image quality.
●
Sub stream: For constant stream, the bit rate changes near the
dened value; for variable stream, the bit rate changes along with
the image but the maximum value still stays near the dened value.
Step 3 Click More.
User's Manual
196
