Figure 5-177 People counting
Step 2 Select a channel, and then click Add.
Step 3 Select the Enable checkbox, and then set Type to People Counting.
Step 4 Draw people counting rule.
1. Click to draw the people counting rule. Right-click the image to stop drawing.
●
Press and hold the vertex of the rule line to adjust the size of the rule line.
●
Click
to delete the drawn rule line.
Table 5-47 Relationship between rule and people counting
Rule
People Counting Type
Drawing detection area. Count the number of people staying in the area.
Draw rule lines within the detection area
and detection area separately.
You can draw polylines for the tripwire,
supporting up to 20 vertices.
Count the number of people crossing the rule lines
within the detection area, such as the number of
people entering, leaving, and passing.
2. Click to draw a target ltering area on the image.
User's Manual
297
