Figure 5-180 Queuing
Step 2 Select a channel, and then click Add.
Step 3 Select the Enable checkbox.
Step 4 Click to draw queuing rule and area.
Step 5 Click under Parameters , and then enable Queue People No. Alarm or Queue Time
Alarm.
Step 6 Click under Trigger to congure alarm schedule and linkage. For details on alarm
linkage, see Table 5-50 .
Step 7 Click Apply.
5.9.12.5 Conguring Abnormal Detection
After conguring queuing alarm, the system can realize the corresponding linkage actions once the
number of people in the queue or the waiting time has triggered an alarm.
Procedure
Step 1 Select Main Menu > AI > Parameters > People Counting > Abnormal Detection.
User's Manual
300
