Figure 3-128
Select SN (object1/2/3/4) and direction, and then input customized rule name.
Object1/2/3/4: System supports four zones. Each SN stands for one zone.
Direction ( / ): For icon , system can generate an alarm once the
object left in the one for the specified time. For icon , system can generate an
alarm once the object is out of the zone for the specified time.
Period: It refers to the object in/out the zone time.
Now you can draw a rule. Left click mouse to draw a line, until you draw a rectangle, you
can right click mouse.
Click Ok to complete the rule setup.
Tips
Click to delete the corresponding rule.
You can refer to the chapter 3.11.3.2 to set parameters.
3.11.3.2.4 Abandoned Object Detection (Optional)
System generates an alarm when there is abandoned object in the specified zone.
From main menu->Setting->Event->IVS, click Add button and then select the type as
abandoned object. The object interface is shown as below. See Figure 3-127.
System supports customized area shape and amount.
Support duration setup.
Support objects filter function.
