Figure 3-132
Name: Input customized rule name.
Period: System can generate an alarm once the object in the zone is missing for the
specified period.
Target filter: Click , you can set filter object size. Each rule can set two sizes (min
size/max size). Once the object is smaller than the min size or larger than the max
size, there is no alarm. Please make sure the max size is larger than the min size.
Now you can draw a rule. Left click mouse to draw a zone, until you draw a rectangle, you
can right click mouse.
Tips
Click to delete the corresponding rule.
Click , you can refer to the chapter 3.11.3.2.1 to set other parameters.
Click Apply to complete the setup.
3.11.3.3 Face Detect (Optional)
The face detection function is optional. The intelligence function and the
human face detection can not be valid at the same time!
