Dahua XVR User Manual

237
The interface is shown as in Figure 4-90. Here you can see HDD information. You can
also operate the read-only, read-write, redundancy (if there are more than on HDD) and
format operation.
Figure 4-90
4.8.4.3 Manual Record
The interface is shown as in Figure 4-91.
Figure 4-91
Please refer to the following sheet for detailed information.
Parameter Function
Channel
Here you can view channel number.
The number displayed here is the max channel amount of your
device.
Status There are three statuses: schedule, manual and stop.
Schedule
System enables auto record function as you set in record schedule
setup (general, motion detect and alarm).

Dahua XVR Specifications

General

Channels	4/8/16
Video Compression	H.265/H.264
Audio Input	Yes
Audio Output	1 channel RCA
Video Output	HDMI/VGA
Recording Resolution	720P
HDD	1 SATA
Network Interface	RJ45
USB Interface	2 USB 2.0
Power Supply	12V DC
Operating Temperature	-10 °C to +55 °C
