Dahua XVR User Manual

244
Figure 4-99
Please refer to the following sheet for detailed information.
Parameter Function
Enable Check the box here to enable this function.
Interval It is to set the interval from current channel group to the next
channel group.
Window split Support 1-window split only.
Delete
Select a channel group and then click to delete it.
Up/Down
Click or to adjust channel tour sequence.
Add channel group
Click ,you can see system pops up the following dialogue box. See Figure 4-100.
Please select the channels and then click OK button.
Figure 4-100
Delete channel group

Dahua XVR Specifications

General

Channels	4/8/16
Video Compression	H.265/H.264
Audio Input	Yes
Audio Output	1 channel RCA
Video Output	HDMI/VGA
Recording Resolution	720P
HDD	1 SATA
Network Interface	RJ45
USB Interface	2 USB 2.0
Power Supply	12V DC
Operating Temperature	-10 °C to +55 °C
