Dahua XVR User Manual

59
 Calculate the record period based on the HDD space
Check the channel you want to record file.
Click Known Space and then click the button to set HDD. Click OK button.
Now you can see the record period (such as 5 days). See Figure 3-54.
Figure 3-54
 Calculate the HDD space based on the record period
Check the channel you want to record file.
Input days(s) you want to records, system can auto calculate the HDD space needed
(such as 5.109TB). See Figure 3-55.

Dahua XVR Specifications

General

Channels	4/8/16
Video Compression	H.265/H.264
Audio Input	Yes
Audio Output	1 channel RCA
Video Output	HDMI/VGA
Recording Resolution	720P
HDD	1 SATA
Network Interface	RJ45
USB Interface	2 USB 2.0
Power Supply	12V DC
Operating Temperature	-10 °C to +55 °C
