Dahua XVR7416L User Manual

409
Parameter
Function
Manual
Add
Click it, the interface is shown as in Figure 5-18. Here you can add
network camera manually.
You can select a channel from the dropdown list (Here only shows
disconnection channel.)
Note:
 System supports manufactures such as Panasonic, Sony,
Dynacolor, Samsung, AXIS, Arecont, Dahua and Onvif standard
protocol.
 If you do not input IP address here. System uses default IP
192.168.0.0 and system does not connect to this IP.
 Can not add two devices at the same time. Click OK button here,
system only connect to the corresponding device of current
channel.
5.8.1.2 Conditions
Here you can view device property information. The setups become valid immediately
after you set.
The analog channel is shown as in Figure 5-19.
Figure 5-19
The digital channel is shown as in Figure 5-20.

Dahua XVR7416L Specifications

General

Brand	Dahua
Model	XVR7416L
Category	DVR
Language	English
