Select a channel group and then click ,you can delete it.
Modify channel group
Select a channel group and then double click, you can see the following interface. See
Figure 5-98. You can change the setup and then click OK button.
Figure 5-98
Adjust channel group sequence.
Click or to change channel sequence.
5.8.5.4 RS232
The RS232 interface is shown as in Figure 5-99.
Figure 5-99
Please refer to the following sheet for detailed information.
Select the corresponding dome protocol.
Default setup is console.
Select the baud rate.
Default setup is 115200.
The value ranges from 5 to 8.
Default setup is 8.
There are two options: 1/2.
Default setup is 1.
There are five options: none/odd/even/space/mark.
