11.2 Configuration wizard
After first power ON of the system, the user interface starts a configuration wizard.
Use this wizard to set the most important initial settings for the unit to run
properly. If required, you can afterwards configure more settings. You can change
all these settings via the menu structure.
You can find a short overview of the settings in the configuration here. All the
settings can also be adjusted in the settings menu (use the breadcrumbs).
For the setting… Refer to…
Language [7.1]
Time/date [7.2]
Hours —
Minutes
Year
Month
Day
System
Indoor unit type (read only) "11.6.9Installer settings"[4216]
Backup heater type [9.3.1]
Domestic hot water [9.2.1]
Emergency [9.5]
Number of zones [4.4] "11.6.5Space heating/
cooling"[4192]
Booster heater capacity [9.4.1]
(if applicable)
"11.6.9Installer settings"[4216]
Backup heater
Voltage [9.3.2] "Backup heater"[4219]
Configuration [9.3.3]
Capacity step 1 [9.3.4]
Additional capacity step 2
[9.3.5] (if applicable)
Main zone
Emitter type [2.7] "11.6.3Main zone"[4177]
Control [2.9]
Setpoint mode [2.4]
Heating WD curve [2.5] (if
applicable)
Cooling WD curve [2.6] (if
applicable)
Schedule [2.1]
WD curve type [2.E]

Daikin Altherma 3 R W Specifications

General

Type	Air-to-water heat pump
Refrigerant	R-32
Energy Efficiency Class (Heating)	A+++
Energy Efficiency Class (Cooling)	A++
Operating Temperature Range (Heating)	-25°C to 35°C
Operating Temperature Range (Cooling)	10°C to 46°C
Heating Capacity	4.0 - 16.0 kW
Sound Power Level	62 dBA
