12 | Commissioning
Installer reference guide
257
ERLA11~16D + EBBH/X11+16D
Daikin Altherma 3 R W
4P643603-1B – 2022.05
4 Select OK to confirm.
Result: The actuator test run starts. It stops automatically when
ready (±30min).
To stop the test run manually: —
1 In the menu, go to Stop test run.
2 Select OK to confirm.
Possible actuator test runs
▪ Booster heater test
▪ Backup heater 1 test
▪ Backup heater 2 test
▪ Pump test
INFORMATION
Make sure that all air is purged before executing the test run. Also avoid disturbances
in the water circuit during the test run.
▪ Shut off valve test
▪ Diverter valve test (3-way valve for switching between space heating and
tank heating)
▪ Bivalent signal test
▪ Alarm output test
▪ C/H signal test
▪ DHW pump test
▪ Bizone kit direct pump test (bizone kit EKMIKPOA or EKMIKPHA)
▪ Bizone kit mixed pump test (bizone kit EKMIKPOA or EKMIKPHA)
▪ Bizone kit mixing valve test (bizone kit EKMIKPOA or EKMIKPHA)
12.4.5 Underfloor heating screed dryout
About underfloor heating screed dryout
Purpose
The underfloor heating (UFH) screed dryout function is used for drying out the
screed of an underfloor heating system during the construction of the building.
NOTICE
The installer is responsible for:
▪ contacting the screed manufacturer for the maximum allowed water
temperature, to avoid cracking the screed,
▪ programming the underfloor heating screed dryout schedule according to the
initial heating instructions of the screed manufacturer,
▪ checking the proper functioning of the setup on a regular basis,
▪ performing the correct program complying with the type of the used screed.
