5 | About the units and options
Installer reference guide
30
ERLA11~16D + EBBH/X11+16D
Daikin Altherma 3 R W
4P643603-1B – 2022.05
Tank Remark
Stainless steel tank (standard):
▪ EKHWS150D3V3
▪ EKHWS180D3V3
▪ EKHWS200D3V3
▪ EKHWS250D3V3
▪ EKHWS300D3V3
Inclusive booster heater
Stainless steel tank (+ components):
▪ EKHWSU150D3V3
▪ EKHWSU180D3V3
▪ EKHWSU200D3V3
▪ EKHWSU250D3V3
▪ EKHWSU300D3V3
Inclusive:
▪ Booster heater
▪ Components to comply with the UK
Building Regulation G3.
Polypropylene tank:
▪ EKHWP300B
▪ EKHWP500B
Tank with drainback solar system.
For these tanks, the booster heater
option (EKBH3SD) must be installed.
Polypropylene tank:
▪ EKHWP300PB
▪ EKHWP500PB
Tank with pressurised solar system.
For these tanks, the booster heater
option (EKBH3SD) must be installed.
For installation instructions, see the installation manual of the domestic hot water
tank, and the addendum book for optional equipment.
Human Comfort Interface (BRC1HHDA) used as room thermostat
▪ The Human Comfort Interface (HCI) used as room thermostat can only be used in
combination with the user interface connected to the indoor unit.
▪ The Human Comfort Interface (HCI) used as room thermostat needs to be
installed in the room that you want to control.
For installation instructions, see the installation and operation manual of the
Human Comfort Interface (HCI) as room thermostat, and the addendum book for
optional equipment.
Smart grid relay kit (EKRELSG)
The installation of the optional Smart grid relay kit is required in case of high
voltage Smart grid contacts (EKRELSG).
For installation instructions, see "9.3.11To connect a Smart Grid"[4140].
5.2.3 Possible combinations of indoor unit and outdoor unit
Indoor unit Outdoor unit
ERLA11 ERLA14 ERLA16
EBBH/X11 O — —
EBBH/X16 — O O
