[60] Counter A (up)
[61] Counter A (down)
[63] Counter B (up)
[64] Counter B (down)
5-16 Terminal X30/3 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is instal-
led in the frequency converter.
Follow the function stated in 5-1*
5-17 Terminal X30/4 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is instal-
led in the frequency converter.
Follow the function stated in 5-1*
5-18 Terminal X30/4 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is instal-
led in the frequency converter.
Follow the function stated in 5-1*
5-19 Terminal 37 Safe Stop
Option: Function:
[1]
*
Safe Stop Alarm Coasts frequency converter when safe stop is activated. Manual
reset from LCP, digital input or fieldbus.
[3] Safe Stop Auto Reset Coasts frequency converter when safe stop is activated (term
37 off). When safe stop circuit is reestablished, the drive will
continue without manual reset.
[4] PTC 1 Alarm Coasts frequency converter when safe stop is activated. Manual
reset from LCP, digital input or fieldbus. Choice 4 is only avail-
able when the MCB 112 PTC Thermistor Card is connected.
[5] PTC 1 Warning Coasts frequency converter when safe stop is activated (term
37 off). When safe stop circuit is reestablished, the drive will
continue without manual reset, unless a Digital Input set to PTC
Card 1 [80] is still enabled. Choice 5 is only available when the
MCB 112 PTC Thermistor Card is connected.
[6] PTC 1 & Relay A This choice is used when the PTC option is gated together with
a Stop button through a Safety relay to T-37. Coasts frequency
converter when safe stop is activated. Manual reset from LCP,
digital input or fieldbus. Choice 6 is only available when the MCB
112 PTC Thermistor Card is connected.
[7] PTC 1 & Relay W This choice is used when the PTC option is gated together with
a Stop button through a Safety relay to T-37. Coasts frequency
converter when safe stop is activated (term 37 off). When safe
stop circuit is reestablished, the drive will continue without man-
