[64] Counter B (Terminal 29 or 33 only) Input for decrement counting in the
SLC counter.
[65] Reset Counter B Input for reset of counter B.
[70] Mech. Brake Feed-
back
Brake feedback for hoisting applications
[71] Mech. Brake Feed-
back inv.
Inverted brake feedback for hoisting applications
[80] PTC Card 1 All Digital Inputs can be set to PTC Card 1 [80]. However, only
one Digital Input must be set to this choice.
5-10 Terminal 18 Digital Input
Option: Function:
[8]
*
Start Select the function from the available digital input range.
5-11 Terminal 19 Digital Input
Option: Function:
[10]
*
Reversing Select the function from the available digital input range.
5-12 Terminal 27 Digital Input
Option: Function:
[2]
*
Coast inverse Select the function from the available digital input range.
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital input range and the
additional options [60], [61], [63] and [64]. Counters are used
in Smart Logic Control functions. This parameter is available for
FC 302 only.
[14]
*
Jog
[60] Counter A (up)
[61] Counter A (down)
[63] Counter B (up)
[64] Counter B (down)
5-14 Terminal 32 Digital Input
Option: Function:
[0]
*
No operation Select the function from the available digital input range.
5-15 Terminal 33 Digital Input
Option: Function:
Select the function from the available digital input range and the
additional options [60], [61], [63] and [64]. Counters are used
in Smart Logic Control functions.
[0]
*
No operation
