[6] Running / no warning Output speed is higher than the speed set in par. 1-81 Min Speed
for Function at Stop [RPM]
. The motor is running and there are
no warnings.
[7] Run in range / no
warning
Motor is running within the programmed current and speed
ranges set in par. 4-50 to par. 4-53. There are no warnings.
[8] Run on reference / no
warning
Motor runs at reference speed.
[9] Alarm An alarm activates the output. There are no warnings.
[10] Alarm or warning An alarm or a warning activates the output.
[11] At torque limit The torque limit set in par. 4-16 or par. 1-17 has been exceeded.
[12] Out of current range The motor current is outside the range set in par. 4-18.
[13] Below current, low Motor current is lower than set in par. 4-50.
[14] Above current, high Motor current is higher than set in par. 4-51.
[15] Out of range Output frequency is outside the frequency range set in any limit
parameter.
[16] Below speed, low Output speed is lower than the setting in par. 4-52.
[17] Above speed, high Output speed is higher than the setting in par. 4-53.
[18] Out of feedback range Feedback is outside the range set in par. 4-56 and 4-57.
[19] Below feedback low Feedback is below the limit set in par. 4-56
Warning Feedback
Low.
[20] Above feedback high Feedback is above the limit set in par. 4-57
Warning Feedback
High
.
[21] Thermal warning The thermal warning turns on when the temperature exceeds
the limit in the motor, the frequency converter, the brake resis-
tor, or the thermistor.
[22] Ready, no thermal
warning
Frequency converter is ready for operation and there is no over-
temperature warning.
[23] Remote, ready, no
thermal warning
Frequency converter is ready for operation and is in Auto On
mode. There is no over-temperature warning.
[24] Ready, no over-/ un-
der voltage
Frequency converter is ready for operation and the mains volt-
age is within the specified voltage range (see
General Specifi-
cations
section).
[25] Reverse
Reversing. Logic ‘1’ when CW rotation of the motor. Logic ‘0’
when CCW rotation of the motor. If the motor is not rotating the
output will follow the reference.
[26] Bus OK Active communication (no time-out) via the serial communica-
tion port.
[27] Torque limit and stop Use in performing a coasting stop and in torque limit condition.
If the frequency converter has received a stop signal and is at
the torque limit, the signal is Logic ‘0’.
[28] Brake, no brake warn-
ing
Brake is active and there are no warnings.
