[29] Brake ready, no fault Brake is ready for operation and there are no faults.
[30] Brake fault (IGBT) Output is Logic ‘1’ when the brake IGBT is short-circuited. Use
this function to protect the frequency converter if there is a fault
on the brake modules. Use the output/relay to cut out the main
voltage from the frequency converter.
[31] Relay 123 Relay is activated when Control Word [0] is selected in param-
eter group 8-**.
[32] Mechanical brake
control
Enables control of an external mechanical brake, see description
in the section
Control of Mechanical Brake
, and par. group 2-2*
[33] Safe stop activated
(FC 302 only)
Indicates that the safe stop on terminal 37 has been activated.
[40] Out of ref range
[41] Below reference low
[42] Above reference high
[45] Bus Ctrl
[46] Bus Ctrl On at timeout
[47] Bus Ctrl Off at timeout
[51] MCO controlled
[55] Pulse output
[60] Comparator 0 See par. group 13-1*. If Comparator 0 is evaluated as TRUE,
the output will go high. Otherwise, it will be low.
[61] Comparator 1 See par. group 13-1*. If Comparator 1 is evaluated as TRUE,
the output will go high. Otherwise, it will be low.
[62] Comparator 2 See par. group 13-1*. If Comparator 2 is evaluated as TRUE,
the output will go high. Otherwise, it will be low.
[63] Comparator 3 See par. group 13-1*. If Comparator 3 is evaluated as TRUE,
the output will go high. Otherwise, it will be low.
[64] Comparator 4 See par. group 13-1*. If Comparator 4 is evaluated as TRUE,
the output will go high. Otherwise, it will be low.
[65] Comparator 5 See par. group 13-1*. If Comparator 5 is evaluated as TRUE,
the output will go high. Otherwise, it will be low.
[70] Logic Rule 0 See par. group 13-4*. If Logic Rule 0 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[71] Logic Rule 1 See par. group 13-4*. If Logic Rule 1 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[72] Logic Rule 2 See par. group 13-4*. If Logic Rule 2 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[73] Logic Rule 3 See par. group 13-4*. If Logic Rule 3 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[74] Logic Rule 4 See par. group 13-4*. If Logic Rule 4 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[75] Logic Rule 5 See par. group 13-4*. If Logic Rule 5 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
