[80] SL Digital Output A See par. 13-52 SL Control Action . The output will go high when-
ever the Smart Logic Action [38]
Set dig. out. A high is executed.
The output will go low whenever the Smart Logic Action [32]
Set dig. out. A low is executed.
[81] SL Digital Output B See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [39]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [33]
Set
dig. out. A low
is executed.
[82] SL Digital Output C See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [40]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [34]
Set
dig. out. A low
is executed.
[83] SL Digital Output D See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [41]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [35]
Set
dig. out. A low
is executed.
[84] SL Digital Output E See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [42]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [36]
Set
dig. out. A low
is executed.
[85] SL Digital Output F See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [43]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [37]
Set
dig. out. A low
is executed.
[120] Local reference active Output is high when par. 3-13
Reference Site = [2] Local or
when par. 3-13
Reference Site = [0] Linked to hand auto at the
same time as the LCP is in Hand on mode.
[121] Remote reference ac-
tive
Output is high when par. 3-13
Reference Site = Remote [1] or
Linked to hand/auto [0] while the LCP is in [Auto on] mode.
[122] No alarm Output is high when no alarm is present.
[123] Start command active Output is high when there is an active Start command (i.e. via
digital input bus connection or [Hand on] or [Auto on]), and no
Stop or Start command is active.
[124] Running reverse Output is high when the drive is running counter clockwise (the
logical product of the status bits ‘running’ AND ‘reverse’).
[125] Drive in hand mode Output is high when the drive is in Hand on mode (as indicated
by the LED light above [Hand on]).
[126] Drive in auto mode Output is high when the drive is in Hand on mode (as indicated
by the LED light above [Auto on]).
5-30 Terminal 27 Digital Output
Option: Function:
[45] Bus ctrl. Controls output via bus. The state of the output is set in par.
5-90. The output state is retained in the event of bus time-out.
