[46] Bus ctrl. on at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set high
(On).
[47] Bus ctrl. off at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set low
(Off).
5-31 Terminal 29 Digital Output
Option: Function:
[45] Bus ctrl. Controls output via bus. The state of the output is set in par.
5-90. The output state is retained in the event of bus time-out.
[46] Bus ctrl. on at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set high
(On).
[47] Bus ctrl. off at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set low
(Off).
This parameter only applies for FC 302.
5-32 Terminal X30/6 Digital Output (MCB 101)
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is moun-
ted in the frequency converter.
Follow the function stated in 5-3*.
5-33 Terminal X30/7 Digital Output (MCB 101)
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is moun-
ted in the frequency converter.
Follow the function stated in 5-3*.
2.8.5. 5-4* Relays
Parameters for configuring the timing and the output functions for the relays.
5-40 Function Relay
Option: Function:
Relay 2 is included in FC 302 only. Par. 5-40 functions are as for
par. 5-3*, including options 36 and 37.
Par. 5-40 options are as for par. 5-30, including options 36 and
37. Relay 2 is included in FC 302 only. Relay 7, 8 and 9 are
included in MCB 105 Relay option module.
[1] (Relay 1)
[2] (Relay 2)
[7] Relay 7
[8] Relay 8
