6-25 Terminal 54 high ref./feedb. value
Range: Function:
1500.00
0 Unit
*
[Par. 6-24 to
1000000.000]
Enter the analog input scaling value that corresponds to the
maximum reference feedback value set in par. 3-03.
6-26 Terminal 54 Filter Time Constant
Range: Function:
0.001s
*
[0.001 - 10.000 s] Enter the time constant. This is a first-order digital low pass filter
time constant for suppressing electrical noise in terminal 54. A
high time constant value improves dampening but also increa-
ses the time delay through the filter.
This parameter cannot be adjusted while the motor is running.
2.9.5. 6-3* Analog Input 3 (MCB 101)
Parameter group for configuring the scale and limits for analog input 3 (X30/11) placed on option
module MCB 101.
6-30 Term. X30/11 Low Voltage
Range: Function:
0.07 V
*
[0 - par. 6-31] Sets the analog input scaling value to correspond to the low
reference/feedback value (set in par. 6-34).
6-31 Term. X30/11 High Voltage
Range: Function:
10.0 V
*
[Par. 6-30 to 10.0 V] Sets the analog input scaling value to correspond to the high
reference/feedback value (set in par. 6-35).
6-34 Term. X30/11 Low Ref./Feedb. Value
Range: Function:
0.000
Unit
*
[1000000.000 to par.
6-35]
Sets the analog input scaling value to correspond to the low
voltage value (set in par. 6-30).
6-35 Term. X30/11 High Ref./Feedb. Value
Range: Function:
1500.00
0 Unit
[Par. 6-34 to
1000000.000]
Sets the analog input scaling value to correspond to the high
voltage value (set in par. 6-31).
6-36 Term. X30/11 Filter Time Constant
Range: Function:
0.001s
*
[0.001 - 10.000 s]
A 1
st
order digital low pass filter time constant for suppressing
electrical noise on terminal X30/11.
Par. 6-36 cannot be changed while the motor is running.
