2.9.6. 6-4* Analog Input 4 (MCB 101)
Parameter group for configuring the scale and limits for analog input 4 (X30/12) placed on option
module MCB 101.
6-40 Term. X30/12 Low Voltage
Range: Function:
0.7 V
*
[0 to par. 6-41] Sets the analog input scaling value to correspond to the low
reference/feedback value set in par. 6-44.
6-41 Term. X30/12 High Voltage
Range: Function:
10.0V
*
[Par. 6-40 to 10.0 V] Sets the analog input scaling value to correspond to the high
reference/feedback value set in par. 6-45.
6-44 Term. X30/12 Low Ref./Feedb. Value
Range: Function:
0.000
Unit
*
[-1000000.000 to par.
6-45]
Sets the analog input scaling value to correspond to the low
voltage value set in par. 6-44.
6-45 Term. X30/12 High Ref./Feedb. Value
Range: Function:
1500.00
0 Unit
*
[Par. 6-44 to
1000000.000]
Sets the analog input scaling value to correspond to the high
voltage value set in par. 6-41.
6-46 Term. X30/12 Filter Time Constant
Range: Function:
0.001s
*
[0.001 - 10.000 s]
A 1
st
order digital low pass filter time constant for suppressing
electrical noise on terminal X30/12.
Par. 6-46 cannot be changed while the motor is running.
2.9.7. 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e. Terminal 42. Analog
outputs are current outputs: 0/4 – 20 mA. Common terminal (terminal 39) is the same terminal
and has the same electrical potential for analog common and digital common connection. Reso-
lution on analog output is 12 bit.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output.
[0] No operation
[52] MCO 305 0-20 mA
[53] MCO 305 4-20 mA
[100] Output frequency
[101] Reference
[102] Feedback
