Danfoss FC 300

16-01 Reference
[Unit]
16-02 Reference %
16-03 Status Word
(Fixed)
16-04 Main Actual
Value [Unit]
16-05 Main Actual
Value (%) (Fixed)
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor Current
16-16 Torque
16-17 Speed [RPM]
16-18 Motor Thermal
16-19 KTY Sensor
Temperature
16-21 Phase Angle
16-30 DC Link Voltage
16-32 BrakeEnergy/s
16-33 BrakeEnergy/2
min
16-34 Heatsink Temp.
16-35 Inverter Ther-
mal
16-38 SL Control
State
16-39 Controlcard
Temp.
16-50 External Refer-
ence
16-51 Pulse Refer-
ence
16-52 Feedback
[Unit]
16-53 Digi Pot Refer-
ence
16-60 Digital Input
16-61 Terminal 53
Switch Setting
16-62 Analog Input
53
16-63 Terminal 54
Switch Setting
16-64 Analog Input
54
