[1650] External Reference Sum of the external reference as a percentage, i.e. the sum of
analog/pulse/bus.
[1651] Pulse Reference Frequency in Hz connected to the digital inputs (18, 19 or 32,
33).
[1652] Feedback [Unit] Reference value from programmed digital input(s).
[1653] Digi Pot Reference
[1660] Digital Input Signal states form the 6 digital terminals (18, 19, 27, 29, 32 and
33). Input 18 corresponds to the bit at the far left. Signal low =
0; Signal high = 1.
[1661] Terminal 53 Switch
Setting
Setting of input terminal 54. Current = 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a reference or protection val-
ue.
[1663] Terminal 54 Switch
Setting
Setting of input terminal 54. Current = 0; Voltage = 1.
[1664] Analog Input 54 Actual value at input 54 either as reference or protection value.
[1665] Analog Output 42
[mA]
Actual value at output 42 in mA. Use par. 6-50 to select the value
to be shown.
[1666] Digital Output [bin] Binary value of all digital outputs.
[1667] Freq. Input #29 [Hz] Actual value of the frequency applied at terminal 29 as an im-
pulse input.
[1668] Freq. Input #33 [Hz] Actual value of the frequency applied at terminal 33 as an im-
pulse input.
[1669] Pulse Output #27
[Hz]
Actual value of impulses applied to terminal 27 in digital output
mode.
[1670] Pulse Output #29
[Hz]
Actual value of impulses applied to terminal 29 in digital output
mode.
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
[1680] Fieldbus CTW 1 Control word (CTW) received from the Bus Master.
[1682] Fieldbus REF 1 Main reference value sent with control word from the Bus Mas-
ter.
[1684] Comm. Option STW Extended fieldbus communication option status word.
[1685] FC Port CTW 1 Control word (CTW) received from the Bus Master.
[1686] FC Port REF 1 Status word (STW) sent to the Bus Master.
[1690] Alarm Word One or more alarms in a Hex code.
[1691] Alarm Word 2 One or more alarms in a Hex code.
[1692] Warning Word One or more warnings in a Hex code.
[1693] Warning Word 2 One or more warnings in a Hex code.
