[1502] kWh Counter
[1600] Control Word Present control word
[1601] Reference [Unit] Total reference (sum of digital/analog/preset/bus/freeze ref./
catch up and slow-down) in selected unit.
[1602] Reference % Total reference (sum of digital/analog/preset/bus/freeze ref./
catch up and slow-down) in percent.
[1603] Status Word Present status word.
[1605] Main Actual Value [%] One or more warnings in a Hex code.
[1609] Custom Readout
[1610] Power [kW] Actual power consumed by the motor in kW.
[1611] Power [hp] Actual power consumed by the motor in HP.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, i.e. the output frequency from the frequency
converter in Hz
[1614] Motor Current Phase current of the motor measured as effective value.
[1615] Frequency [%] Motor frequency, i.e. the output frequency from the frequency
converter in percent.
[1616] Torque Present motor load as a percentage of the rated motor torque.
[1617]
*
Speed [RPM] Speed in RPM (revolutions per minute) i.e. the motor shaft
speed in closed loop.
[1618] Motor Thermal Thermal load on the motor, calculated by the ETR function.
[1619] KTY Sensor Tempera-
ture
[1620] Motor Angle
[1621] Phase Angle
[1622] Torque %
[1630] DC Link Voltage Intermediate circuit voltage in the frequency converter.
[1632] BrakeEnergy/s Present brake power transferred to an external brake resistor.
Stated as an instantaneous value.
[1633] BrakeEnergy/2 min Brake power transferred to an external brake resistor. The mean
power is calculated continuously for the most recent 120 sec-
onds.
[1634] Heatsink Temp. Present heat sink temperature of the frequency converter. The
cut-out limit is 95 ±5 oC; cutting back in occurs at 70 ±5° C.
[1635] Inverter Thermal Percentage load of the inverters.
[1636] Inv. Nom. Current Nominal current of the frequency converter.
[1637] Inv. Max. Current Maximum current of the frequency converter.
[1638] SL Control State State of the event executed by the control.
[1639] Control Card Temp. Temperature of the control card.
FC 300 Programming Guide 2. How to Programme
