Danfoss FC 300

Array [5]
0 *
[0 - 255] View a list of all the set-ups linked by means of par. 0-12 This
Set-up Linked to
. The parameter has one index for each pa-
rameter set-up. The parameter value displayed for each index
represents which setups are linked to that parameter setup.
Index
LCP value
0 {0}
1 {1,2}
2 {1,2}
3{3}
4 {4}
Table 2.1: Example: Set-up 1 and Set-up 2 are linked
0-14 Readout: Edit Set-ups / Channe
Range: Function:
0
*
[0 - FFF.FFF.FFF] View the setting of par. 0-11 Edit Set-up for each of the four
different communication channels. When the number is dis-
played in hex, as it is in the LCP, each number represents one
channel.
Numbers 1-4 represent a set-up number; ‘F’ means factory set-
ting; and ‘A’ means active set-up. The channels are, from right
to left: LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means that the FC bus se-
lected Set-up 2 in par. 0-11, the LCP selected Set-up 1 and all
others used the active set-up.
2.3.4. 0-2* LCP Display
Define the variables displayed in the Graphical Local Control Panel.
NB!
Please refer to parameters 0-37, 0-38 and 0-39 for information on how to write
display texts
Select a variable for display in line 1, left position.
[0] None No display value selected.
[953] Profibus Warning
Word
[1005] Readout Transmit Er-
ror Counter
[1006] Readout Receive Er-
ror Counter
[1007] Readout Bus Off
Counter
[1013] Warning Parameter
[1501] Running Hours
2. How to Programme FC 300 Programming Guide
32 MG.33.M2.02 - VLT
®
is a registered Danfoss trademark
