4. RemovethenylonnutsatthebaseoftheDCCapacitorBusBarAssembly,underthemaincompressor
housing.RefertoFigure4-186CapacitorNutRemoval-TTS/TGS/TTH/TGH(ExceptTTS300/TGS230).
Figure 4-186 Capacitor Nut Removal - TTS/TGS/TTH/TGH (Except TTS300/TGS230)

5. CarefullylifttheDCBusBarsandcapacitorsoutasanassembly.Donotremovethebleedresistors,
BalanceBoard,orcapacitorsfromthebusbars.RefertoFigure4-187CapacitorAssemblyRemoval-
TTS/TGS/TTH/TGHRev.FandEarlier(ExceptTTS300/TGS230)onpage173andFigure4-188Capacitor
AssemblyRemoval-TTS/TGS/TTH/TGHRev.H(ExceptTTS300/TGS230)onpage173.

• • • DANGER! • • •
BleedResistorsandbusbarsmayhavesharpedges.Usecautionandwearappropriateprotectivegearwhenremovingthecapacitor
assembly.


Page 172 of 294 - M-SV-001-EN Rev. H 1/23/2023
