Function:
This parameter is used for setting the signal value that
has to correspond to the minimum reference or the
minimum feedback, parameter 204 Minimum refer-
ence, Ref
MIN
/413 Minimum feedback, FB
MIN
. See
Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long signal
lines can be compensated for.
If the time-out function is to be applied (parameters
317 Time out and 318 Function after time out), the value
must be set to > 1 V.
310 Terminal 53, max. scaling
(AI 53 SCALE HIGH)
Value:
0.0 - 10.0 V
10.0 V
Function:
This parameter is used for setting the signal value that
has to correspond to the maximum reference value or
the maximum feedback, parameter 205 Maximum ref-
erence, Ref
MAX
/414 Maximum feedback, FB
MAX
. See
Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long signal
lines can be compensated for.
311 Terminal 54, analog input voltage
(AI [V] 54 FUNCT.)
Value:
See description of parameter
308.
No operation
Function:
This parameter chooses between the different func-
tions available for the input, terminal 54.
Scaling of the input signal is done in parameter 312
Terminal 54, min. scaling and in parameter 313 Termi-
nal 54, max. scaling.
Description of choice:
See description of parameter 308.
For reasons of accuracy, voltage losses in long signal
lines should be compensated for.
312 Terminal 54, min. scaling
(AI 54 SCALE LOW)
Value:
0.0 - 10.0 V
0.0 V
Function:
This parameter is used for setting the signal value that
corresponds to the minimum reference value or the
minimum feedback, parameter 204 Minimum refer-
ence, Ref
MIN
/413 Minimum feedback, FB
MIN
. See
Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long signal
lines can be compensated for.
If the time-out function is to be applied (parameters
317 Time out and 318 Function after time out), the value
must be set to > 1 V.
313 Terminal 54, max. scaling
(AI 54 SCALE HIGH)
Value:
0.0 - 10.0 V
10.0 V
Function:
This parameter is used for setting the signal value that
corresponds to the maximum reference value or the
maximum feedback, parameter 205 Maximum refe-
rence, Ref
MAX
/414 Maximum feedback, FB
MAX
. See
Reference handling or Feedback handling.
Description of choice:
Set the required voltage value.
For reasons of accuracy, voltage losses in long signal
lines can be compensated for.
314 Terminal 60, analogue input current
(AI [mA] 60 FUNCT.)
Value:
See description of parameter 308.
Reference
Function:
This parameter allows a choice between the different
functions available for the input, terminal 60.
Scaling of the input signal is effected in parameter 315
Terminal 60, min. scaling and in parameter 316 Termi-
nal 60, max. scaling.
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.61.B5.02 - VLT
®
is a registered Danfoss trademark 129
Programming
