Page #131 background imageLoading...
Page #131 background image
Analog/digital outputs
The two analog/digital outputs (terminals 42 and 45)
can be programmed to show the present status or a
process value such as 0 - f
MAX
. If the frequency con-
verter is used as a digital output, it gives the present
status by means of 0 or 24 V DC.
If the analog output is used for giving a process value,
there is a choice of three types of output signal:
0-20 mA, 4-20 mA or 0-32000 pulses (depending on
the value set in parameter 322 Terminal 45, output,
pulse scaling.
If the output is used as a voltage output (0-10 V), a pull-
down resistor of 500 should be fitted to terminal 39
(common for analog/digital outputs). If the output is
used as a current output, the resulting impedance of
the connected equipment should not exceed 500 .
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.61.B5.02 - VLT
®
is a registered Danfoss trademark 131
Programming
