Programming
Using the [EXTEND MENU] key, it is
possible to have access to all the pa-
rameters for the frequency converter.
Operation and Display 001-017
This parameter group allows to set up parameters
such as language, display readout and the possibility
of making the function keys on the control unit inactive.
001 Language
(LANGUAGE)
Value:
English (ENGLISH) [0]
German (DEUTSCH) [1]
French (FRANCAIS) [2]
Danish (DANSK) [3]
Spanish (ESPAÑOL) [4]
Italian (ITALIANO) [5]
Swedish (SVENSKA) [6]
Dutch (NEDERLANDS) [7]
Portuguese (PORTUGUESA) [8]
Finnish (SUOMI) [9]
State when delivered may vary from factory setting.
Function:
The choice in this parameter defines the language to
be used on the display.
Description of choice:
There is a choice of the languages indicated.
The Setup configuration
The frequency converter has four Setups (parameter
Setups) that can be programmed independently of
each other. The active Setup can be selected in pa-
rameter 002 Active Setup. The active Setup number
will be shown in the display under "Setup". It is also
possible to set the frequency converter to Multi-Setup
to allow switching of Setups with the digital inputs or
serial communication.
Setup shifts can be used in systems where, one Setup
is used during the day and another at night.
Parameter 003 Copying of Setups enables copying
from one Setup to another.
By means of parameter 004 LCP copy, all Setups can
be transferred from one frequency converter to anoth-
er by moving the control panel. First all parameter
values are copied to the control panel. This can then
be moved to another frequency converter, where all
parameter values can be copied from the control unit
to the frequency converter.
002 Active Setup
(ACTIVE SETUP)
Value:
Factory Setup (FACTORY SETUP) [0]
Setup 1 (SETUP 1) [1]
Setup 2 (SETUP 2) [2]
Setup 3 (SETUP 3) [3]
Setup 4 (SETUP 4) [4]
MultiSetup (MULTI SETUP) [5]
Function:
The choice in this parameter defines the Setup number
you want to control the functions of the frequency con-
verter. All parameters can be programmed in four
individual parameter Setups, Setup 1 - Setup 4.
In addition, a pre-programmed Setup called the Fac-
tory Setup exists. This only allows specific parameters
to be changed.
Description of choice:
Factory Setup [0] contains the parameter values pre-
set at the factory. Can be used as a data source if the
other Setups are to be returned to a common state. In
this case Factory Setup is selected as the active Set-
up.
Setups 1-4 [1]-[4] are four individual Setups that can
be selected as required.
MultiSetup [5] is used if remote switching between dif-
ferent Setups is required. Terminals 16/17/29/32/33
and the serial communication port can be used for
switching between Setups.
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
100 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
