Changing data
Regardless of whether a parameter has been selected
under the Quick menu or the Extended menu, the pro-
cedure for changing data is the same. Pressing the
[CHANGE DATA] key allows change of the selected
parameter, and the underlining in line 4 will flash on
the display.
The procedure for changing data depends on whether
the selected parameter represents a numerical data
value or a functional value.
If the chosen parameter represents a numeric data
value, the first digit can be changed by means of the
[+/-] keys. If the second digit is to be changed, first
move the cursor by using the [<>] keys, then change
the data value using the [+/-] keys.
175ZA698.10
24.2 Hz
SETUP
1
FREQUENCY
205 MAX. REFERENCE
000060,000 Hz
5
The selected digit is indicated by a flashing cursor. The
bottom display line gives the data value that will be
entered (saved) when signing off by pressing the [OK]
button. Use [CANCEL] to cancel the change.
If the selected parameter is a functional value, the se-
lected text value can be changed by means of the [+/-]
keys.
175ZA689.10
3.90 A
SETUP
1
210 REFERENCE TYPE
SUM
MOTOR CURRENT
The functional value flashes until signing off by press-
ing the [OK] button. The functional value has now been
selected. Use [CANCEL] to cancel the change.
Infinitely variable change of numeric data value
If the chosen parameter represents a numeric data
value, a digit is first selected by means of the [<>] keys.
175ZA699.10
SETUP
1
50.0 Hz
FREQUENCY
209 JOG FREQUENCY
0
9 .0 Hz
SETUP
1
Then the chosen digit is changed infinitely by means
of the [+/-] keys:
175ZA700.10
SETUP
1
50.0
FREQUENCY
209 JOG FREQUENCY
1
0.0 Hz
SETUP
1
The chosen digit flashes. The bottom display line
shows the data value that will be entered (saved) when
signing off with [OK].
Changing of data value, step-by-step
Certain parameters can be changed both step by step
and infinitely variably. This applies to Motor power (pa-
rameter 102), Motor voltage (parameter 103) and
Motor frequency (parameter 104).
This means that the parameters are changed both as
a group of numeric data values and as numeric data
values infinitely variably.
Manual initialisation
Disconnect from mains and hold the [DISPLAY
MODE] + [CHANGE DATA] + [OK] keys down while at
the same time reconnecting the mains supply. Re-
lease the keys; the frequency converter has now been
programmed for the factory setting.
The following parameters are not zeroed by means of manual
initialisation:
Parameter
500, Protocol
600, Operating hours
601, hours run
602, kWh counter
603, Number of power-ups
604, Number of overtemperatures
605, Number of overvoltages
It is also possible to carry out initialisation via param-
eter 620 Operating mode.
VLT
®
6000 HVAC Series
MG.61.B5.02 - VLT
®
is a registered Danfoss trademark 97
Programming
