Choice of frequency converter
The frequency converter should be chosen on the ba-
sis of the given motor current at maximum load on the
system. The rated output current I
VLT,N
must be equal
to or higher than the required motor current.
VLT 6000 HVAC is available for three mains voltage
ranges: 200-240 V, 380-460 V, and 525-600 V.
Choose mains voltage for 50/60 Hz:
- 200-240 V three-phase AC voltage
- 380-460 V three-phase AC voltage
- 525-600 V three-phase AC voltage
Mains voltage 200 - 240 V
Typical shaft output
Max continuous output current Max continuous output power
P
VLT,N
I
VLT,N
at 240 V S
VLT,N
VLT type [kW] [HP] [A] [kVA]
6002
1.1 1.5 6.6 2.7
6003 1.5 2.0 7.5 3.1
6004 2.2 3.0 10.6 4.4
6005 3.0 4.0 12.5 5.2
6006 4.0 5.0 16.7 6.9
6008 5.5 7.5 24.2 10.1
6011 7.5 10 30.8 12.8
6016 11 15 46.2 19.1
6022 15 20 59.4 24.7
6027 18.5 25 74.8 31.1
6032 22 30 88.0 36.6
6042 30 40 115/104* 43.2
6052 37 50 143/130* 54.0
6062 45 60 170/154* 64.0
*The first figure is for a motor voltage of 200-230 V.
The next figure is for a motor voltage of 231-240 V.
Mains voltage 380 - 415 V
Typical shaft output Max continuous output current Max continuous output power
P
VLT.N
I
VLT.N
at 400 V S
VLT.N
VLT type [kW] [A] [kVA]
6002
1.1 3.0 2.2
6003 1.5 4.1 2.9
6004 2.2 5.6 4.0
6005 3.0 7.2 5.2
6006 4.0 10.0 7.2
6008 5.5 13.0 9.3
6011 7.5 16.0 11.5
6016 11 24.0 17.3
6022 15 32.0 23.0
6027 18.5 37.5 27.0
6032 22 44.0 31.6
6042 30 61.0 43.8
6052 37 73.0 52.5
6062 45 90.0 64.7
6072 55 106 73.4
6102 75 147 102
6122 90 177 123
6152 110 212 147
6172 132 260 180
6222 160 315 218
6272 200 395 274
6352 250 480 333
6402 315 600 416
6502 355 658 456
6552 400 745 516
6602 450 800 554
VLT
®
6000 HVAC Series
24 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
