Quick Menu
The QUICK MENU key gives access to 12 of the most
important setup parameters of the drive. After pro-
gramming, the drive will, in many cases, be ready for
operation. The 12 Quick Menu parameters are
shown in the table below. A complete description of the
function is given in the parameter sections of this man-
ual.
Quick Menu
Parameter Description
Item Number Name
1 001 Language Selects language used for all displays.
2 102 Motor Power Sets output characteristics of drive based on kW size of
motor.
3 103 Motor Voltage Sets output characteristics of drive based on voltage of-
motor.
4 104 Motor Frequency Sets output characteristics of drive based on nominal fre-
quency of motor. This is typically equal to line frequency.
5 105 Motor Current Sets output characteristics of drive based on nominal cur-
rent in amps of motor.
6 106 Motor Nominal Speed Sets output characteristics of drive based on nominal full
load speed of motor.
7 201 Minimum Frequency Sets minimum controlled frequency at which motor will
run.
8 202 Maximum Frequency Sets maximum controlled frequency at which motor will
run.
9 206 Ramp Up Time Sets time to accelerate motor from 0 Hz to nominal motor
frequency set in Quick Menu Item 4.
10 207 Ramp Down Time Sets time to decelerate motor from nominal motor fre-
quency set in Quick Menu Item 4 to 0 Hz.
11 323 Relay1 Function Sets function of high voltage Form C relay.
12 326 Relay 2 Function Sets function of low voltage Form A relay.
VLT
®
6000 HVAC Series
98 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
