Analog/digital outputs terminal no. 42 45
parameter 319 321
No function (NO FUNCTION) [0] [0]
Drive ready (UN. READY) [1] [1]
Standby (STAND BY) [2] [2]
Running (RUNNING) [3] [3]
Running at ref. value (RUNNING AT REFERENCE) [4] [4]
Running, no warning (RUNNING NO WARNING) [5] [5]
Local reference active (DRIVE IN LOCAL REF.) [6] [6]
Remote references active (DRIVE IN REMOTE REF.) [7] [7]
Alarm (ALARM) [8] [8]
Alarm or warning (ALARM OR WARNING) [9] [9]
No alarm (NO ALARM) [10] [10]
Current limit (CURRENT LIMIT) [11] [11]
Safety interlock (SAFETY INTERLOCK) [12] [12]
Start command active (START SIGNAL APPLIED) [13] [13]
Reversing (RUNNING IN REVERSE) [14] [14]
Thermal warning (THERMAL WARNING) [15] [15]
Hand mode active (DRIVE IN HAND MODE) [16] [16]
Auto mode active (DRIVE IN AUTO MODE) [17] [17]
Sleep mode (SLEEP MODE) [18] [18]
Output frequency lower than f
LOW
parameter 223 (F OUT < F LOW)
[19] [19]
Output frequency higher than f
HIGH
parameter 223 (F OUT > F HIGH)
[20] [20]
Out of frequency range (FREQ. RANGE WARN.) [21] [21]
Output current lower than I
LOW
parameter 221 (I OUT < I LOW)
[22] [22]
Output current higher than I
HIGH
parameter 222 (I OUT > I HIGH)
[23] [23]
Out of current range (CURRENT RANGE WARN) [24] [24]
Out of feedback range (FEEDBACK RANGE WARN.) [25] [25]
Out of reference range (REFERENCE RANGE WARN) [26] [26]
Relay 123 (RELAY 123) [27] [27]
Mains imbalance (MAINS IMBALANCE) [28] [28]
Output frequency, 0 - f
MAX
⇒0-20 mA (OUT. FREQ. 0-20 mA)
[29] [29]
Output frequency, 0 - f
MAX
⇒4-20 mA (OUT. FREQ. 4-20 mA)
[30] [30]
Output frequency (pulse sequence), 0 - f
MAX
⇒0-32000 p (OUT. FREQ. PULSE)
[31] [31]
External reference, Ref
MIN
- Ref
MAX
⇒0-20 mA (EXT. REF. 0-20 mA)
[32] [32]
External reference, Ref
MIN
- Ref
MAX
⇒4-20 mA (EXTERNAL REF. 4-20 mA)
[33] [33]
External reference (pulse sequence), Ref
MIN
- Ref
MAX
⇒0-32000 p (EXTERNAL REF. PULSE)
[34] [34]
Feedback, FB
MIN
- FB
MAX
⇒0-20 mA (FEEDBACK 0-20 mA)
[35] [35]
Feedback, FB
MIN
- FB
MAX
⇒4-20 mA (FEEDBACK 4-20 mA)
[36] [36]
Feedback (pulse sequence), FB
MIN
- FB
MAX
⇒0 - 32000 p (FEEDBACK PULSE)
[37] [37]
Output current, 0 - I
MAX
⇒0-20 mA (MOTOR CUR. 0- 20 mA)
[38] [38]
Output current, 0 - I
MAX
⇒4-20 mA (MOTOR CUR. 4- 20 mA)
[39] [39]
Output current (pulse sequence), 0 - I
MAX
⇒0 - 32000 p (MOTOR CUR. PULSE)
[40] [40]
Output power, 0 - P
NOM
⇒0-20 mA (MOTOR POWER 0-20 mA)
[41] [41]
Output power, 0 - P
NOM
⇒4-20 mA (MOTOR POWER 4-20 mA)
[42] [42]
Output power (pulse sequence), 0 - P
NOM
⇒0- 32000 p (MOTOR POWER PULSE)
[43] [43]
Bus control, 0.0-100.0% ⇒0-20 mA (BUS CONTROL 0-20 MA) [44] [44]
Bus control, 0.0-100.0% ⇒4-20 mA (BUS CONTROL 4-20 MA) [45] [45]
Bus control (pulse sequence), 0.0-100.0%⇒0 - 32.000 Pulses (BUS CONTROL PULS) [46] [46]
Fire mode active (FIRE MODE ACTIVE) [47] [47]
Fire mode bypass (FIRE MODE BYPASS) [48] [48]
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
