319 Terminal 42, output
(AO 42 FUNCTION)
Function:
This output can act both as a digital or an analog out-
put. If used as a digital output (data value [0]-[59]), a
0/24 V DC signal is transmitted; if used as an analog
output, either a 0-20 mA signal, a 4-20 mA signal or a
pulse sequence of 0-32000 pulses is transmitted.
Description of choice:
No function. Selected if the frequency converter is not
to react to signals.
Drive ready. The frequency converter control card re-
ceives a supply voltage and the frequency converter is
ready for operation.
Stand by. The frequency converter is ready for oper-
ation, but no start command has been given. No warn-
ing.
Running Is active when there is a start command or
the output frequency is above 0.1 Hz.
Running at ref. value. Speed according to reference.
Running, no warning. A start command has been
given. No warning.
Local reference active. The output is active when the
motor is controlled by means of the local reference via
the control unit.
Remote references active. The output is active when
the frequency converter is controlled by means of the
remote references.
Alarm. The output is activated by an alarm.
Alarm or warning. The output is activated by an alarm
or a warning.
No alarm. The output is active when there is no alarm.
Current limit. The output current is greater than the
value programmed in parameter 215 Current limit I
LIM
.
Safety interlock. The output is active when terminal
27 is a logic ‘1’ and Safety interlock has been selected
on the input.
Start command active. A start command has been
given.
Reversing. There is 24 V DC on the output when the
motor rotates anti-clockwise. When the motor rotates
clockwise, the value is 0 V DC.
Thermal warning. The temperature limit in either the
motor, the frequency converter or a thermistor con-
nected to an analog input has been exceeded.
Hand mode active. The output is active when the fre-
quency converter is in Hand mode.
Auto mode active. The output is active when the fre-
quency converter is in Auto mode.
Sleep mode. Active when the frequency converter is
in Sleep mode.
Output frequency lower than f
LOW
. The output fre-
quency is lower than the value set in parameter 223
Warning: Low frequency, f
LOW
.
Outout frequency higher than f
high
. The output fre-
quency is higher than the value set in parameter 224
Warning: High frequency, f
HIGH
.
Out of frequency range. The output frequency is out-
side the frequency range programmed in parameter
223 Warning: Low frequency, f
LOW
and 224 Warning:
High frequency, f
HIGH
.
Output current lower than I
LOW
. The output current
is lower than the value set in parameter 221 Warning:
Low current, I
LOW
.
Output current higher than I
HIGH
. The output current
is higher than the value set in parameter 222 Warning:
High current, I
HIGH
.
Out of current range. The output current is outside
the range programmed in parameter 221 Warning: Low
current, I
LOW
and 222 Warning, High current, I
HIGH
.
Out of feedback range. The feedback signal is out-
side the range programmed in parameter 227 Warning:
Low feedback, FB
LOW
and 228 Warning: High feed-
back, FB
HIGH
.
Out of reference range. The reference lies outside
the range programmed in parameter 225 Warning: Low
reference, Ref
LOW
and 226Warning, High reference,
Ref
HIGH
.
Relay 123. This function is only used when a profibus
option card is installed.
Mains imbalance. This output is activated at too high
mains imbalance or when a phase is missing in the
mains supply. Check the mains voltage to the frequen-
cy converter.
0-f
MAX
⇒ 0-20 mA and
0-f
MAX
⇒ 4-20 mA and
0-f
MAX
⇒ 0-32000 p which generates an output signal
proportional to the output frequency in the interval 0 -
f
MAX
(parameter 202 Output frequency, high limit, f
MAX
).
External Ref
min
- Ref
max
⇒
0-20 mA and
External Ref
min
- Ref
max
⇒
4-20 mA and
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.61.B5.02 - VLT
®
is a registered Danfoss trademark 133
Programming
