509 - 532Data read-out
Value:
Parameter Description Display text Unit Updating
no. interval
509
Resulting reference (REFERENCE %) % 80 msec.
510 Resulting reference [unit] (REFERENCE [UNIT]) Hz, rpm 80 msec.
511 Feedback [unit] (FEEDBACK) Par. 415 80 msec.
512 Frequency [Hz] (FREQUENCY) Hz 80 msec.
513 User-defined read-out (CUSTOM READOUT) Hz x scaling 80 msec.
514 Motor current [A] (CURRENT) Amp 80 msec.
515 Power [kW] (POWER KW) kW 80 msec.
516 Power [HP] (POWER HK) HP 80 msec.
517 Motor voltage [V] (MOTOR VOLT) V
AC
80 msec.
518 DC link voltage [V] (DC LINK VOLTAGE) V
DC
80 msec.
519 Thermal load, motor [%] (MOTOR TEMPERATURE) % 80 msec.
520 Thermal load, VLT [%] (VLT TEMPERATURE) % 80 msec.
521 Digital input (DIGITAL INPUT) Binary 80 msec.
522 Terminal 53, analogue input [V] (TERMINAL 53, ANALOG INPUT) Volt 20 msec.
523 Terminal 54, analogue input [V] (TERMINAL 54, ANALOG INPUT) Volt 20 msec.
524 Terminal 60, analogue input [mA] (TERMINAL 60, ANALOG INPUT) mA 20 msec.
525 Pulse reference [Hz] (PULSE REFERENCE) Hz 20 msec.
526 External reference [%] (EXTERNAL REFERENCE) % 20 msec.
527 Status word (STATUS WORD HEX) Hex 20 msec.
528 Heat sink temperature [°C] (HEAT SINK TEMP.) °C 1.2 msec.
529 Alarm word (ALARM WORD, HEX) Hex 20 msec
530 Control word (VLT CONTROL WORD, HEX) Hex 2 msec
531 Warning word (WARNING WORD) Hex 20 msec
532 Extended status word (STATUS WORD) Hex 20 msec
537 Relay status (RELAY STATUS) Binary 80 msec
538 Warning word 2 (WARNING WORD 2) Hex 20 msec
Function:
These parameters can be read out via the serial com-
munication port and via the display. See also param-
eters 007-010 Display read-out.
Description of choice:
Resulting reference, parameter 509:
gives a percentage for the resulting reference in the
range from Minimum reference, Ref
MIN
to Maximum
reference, Ref
MAX
. See also reference handling, page
98.
Resulting reference [unit], parameter 510:
gives the resulting reference by means of the unit Hz
in Open loop (parameter 100). In Closed loop , the re-
ference unit is selected in parameter 415 Units with
closed loop.
Feedback [unit], parameter 511:
gives the resulting feedback value by means of the
unit/scaling selected in parameters 413, 414 and 415.
See also feedback handling, page 124.
Frequency [Hz], parameter 512:
gives the output frequency from the frequency con-
verter.
Description of choice:
User-defined read-out, parameter 513:
gives a user-defined value calculated on the basis of
the present output frequency and unit, as well as the
scaling in selected in parameter 005 Max. value of
user-defined read-out. The unit is selected in parame-
ter 006 Unit for user-defined read-out.
Motor current [A], parameter 514:
Gives the motor phase current measured as an effec-
tive value.
Power [kW], parameter 515:
Gives the present power absorption of the motor in kW.
Power [HP], parameter 516:
Gives the present power absorption of the motor in HP.
Motor voltage, parameter 517:
Gives the voltage fed to the motor.
DC link voltage, parameter 518:
Gives the intermediate circuit voltage of the frequency
converter.
Thermal load, motor [%], parameter 519:
Gives the calculated/estimated thermal load on the
motor. 100 % is the cut-out limit. See also parameter
117 Motor thermal protection.
Thermal protection, VLT [%], parameter 520:
Gives the calculated/estimated thermal load on the
frequency converter. 100 % is the cut-out limit.
Digital input, parameter 521:
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
170 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
