No. Description Warning Alarm Trip locked
1
10 Volts low (10 VOLT LOW) x
2 Live zero fault (LIVE ZERO ERROR) x x
4 Mains imbalance (MAINS IMBALANCE) x x x
5 Voltage warning high (DC LINK VOLTAGE HIGH) x
6 Voltage warning low (DC LINK VOLTAGE LOW) x
7 Overvoltage (DC LINK OVERVOLT) x x
8 Undervoltage (DC LINK UNDERVOLT) x x
9 Inverter overloaded (INVERTER TIME) x x
10 Motor overloaded (MOTOR TIME) x x
11 Motor thermistor (MOTOR THERMISTOR) x x
12 Current limit (CURRENT LIMIT) x x
13 Overcurrent (OVERCURRENT) x x x
14 Earth fault (EARTH FAULT) x x
15 Switch mode fault (SWITCH MODE FAULT) x x
16 Short-circuit (CURR.SHORT CIRCUIT) x x
17 Serial communication timeout (STD BUSTIMEOUT) x x
18 HPFB bus timeout (HPFB TIMEOUT) x x
19 Fault in EEprom on power card (EE ERROR POWER) x
20 Fault in EEprom on control card (EE ERROR CONTROL) x
22 Auto-optimisation not OK (AMA FAULT) x
29 Heat-sink temperature too high (HEAT SINK OVERTEMP.) x
30 Motor phase U missing (MISSING MOT.PHASE U) x
31 Motor phase V missing (MISSING MOT.PHASE V) x
32 Motor phase W missing (MISSING MOT.PHASE W) x
34 HPFB communication fault (HPFB COMM. FAULT) x x
37 Inverter fault (GATE DRIVE FAULT) x x
39 Check parameters 104 and 106 (CHECK P.104 & P.106) x
40 Check parameters 103 and 105 (CHECK P.103 & P.106) x
41 Motor too big (MOTOR TOO BIG) x
42 Motor too small (MOTOR TOO SMALL) x
60 Safety stop (EXTERNAL FAULT) x
61 Output frequency low (FOUT < FLOW) x
62 Output frequency high (FOUT > FHIGH) x
63 Output current low (I MOTOR < I LOW) x x
64 Output current high (I MOTOR > I HIGH) x
65 Feedback low (FEEDBACK < FDB LOW) x
66 Feedback high (FEEDBACK > FDB HIGH) x
67 Reference low (REF. < REF. LOW) x
68 Reference high (REF. > REF. HIGH) x
69 Temperature auto derate (TEMP.AUTO DERATE) x
80 Fire mode was active (FIRE MODE WAS ACTIVE) x x
81 RTC not ready (RTC NOT READY) x
99 Unknown fault (UNKNOWN ALARM) x x
VLT
®
6000 HVAC Series
188 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
