Danfoss VLT 6000 HVAC Series

PNU Parameter Factory setting Range Changes 4-Setup
Conver-
sion
Data
# description during operation index type
200 Output frequency range 0 - 120 Hz 0 - 1000 Hz No Yes 0 5
201 Output frequency low limit, f
MIN
0.0 Hz 0.0 - f
MAX
Yes Yes -1 6
202 Output frequency high limit, f
MAX
50 Hz f
MIN
- par. 200 Yes Yes -1 6
203 Reference site Hand/Auto linked reference Yes Yes 0 5
204 Minimum reference, Ref
MIN
0.000 0.000-par. 100 Yes Yes -3 4
205 Maximum reference, Ref
MAX
50.000 par. 100-999.999,999 Yes Yes -3 4
206 Ramp-up time Depends on the unit 1 - 3600 Yes Yes 0 7
207 Ramp-down time Depends on the unit 1 - 3600 Yes Yes 0 7
208 Automatic ramp-up/down Enable Yes Yes 0 5
209 Jog frequency 10.0 Hz 0.0 - par. 100 Yes Yes -1 6
210 Reference type Sum Yes Yes 0 5
211 Preset reference 1 0.00 % -100.00 - 100.00 % Yes Yes -2 3
212 Preset reference 2 0.00 % -100.00 - 100.00 % Yes Yes -2 3
213 Preset reference 3 0.00 % -100.00 - 100.00 % Yes Yes -2 3
214 Preset reference 4 0.00 % -100.00 - 100.00 % Yes Yes -2 3
215 Current limit, l
LIM
1.0 x l
VLT,N[A]
0,1-1,1 x l
VLT,N[A]
Yes Yes -1 6
216 Frequency bypass, bandwidth 0 Hz 0 - 100 Hz Yes Yes 0 6
217 Frequency bypass 1 120 Hz 0.0 - par.200 Yes Yes -1 6
218 Frequency bypass 2 120 Hz 0.0 - par.200 Yes Yes -1 6
219 Frequency bypass 3 120 Hz 0.0 - par.200 Yes Yes -1 6
220 Frequency bypass 4 120 Hz 0.0 - par.200 Yes Yes -1 6
221 Warning: Low current, l
LOW
0.0 A 0.0 - par.222 Yes Yes -1 6
222 Warning: High current, l
HIGH
l
VLT,MAX
Par.221 - l
VLT,MAX
Yes Yes -1 6
223 Warning: Low frequency, f
LOW
0.0 Hz 0.0 - par.224 Yes Yes -1 6
224 Warning: High frequency, f
HIGH
120.0 Hz Par.223 - par.200/202 Yes Yes -1 6
225 Warning: Low reference, Ref
LOW
-999,999.999 -999,999.999 - par.226 Yes Yes -3 4
226 Warning: High reference, Ref
HIGH
999,999.999 Par.225 - 999,999.999 Yes Yes -3 4
227 Warning: Low feedback, FB
LOW
-999,999.999 -999,999.999 - par.228 Yes Yes -3 4
228 Warning: High feedback, FB
HIGH
999,999.999 Par. 227 - 999,999.999 Yes Yes -3 4
Changes during operation:
"Yes" means that the parameter can be changed,
while the frequency converter is in operation. "No"
means that the frequency converter must be stopped
before a change can be made.
4-Setup:
"Yes" means that the parameter can be programmed
individually in each of the four setups, i.e. the same
parameter can have four different data values. "No"
means that the data value will be the same in all four
setups.
Conversion index:
This number refers to a conversion figure to be used
when writing or reading by means of a frequency con-
verter.
Conversion index Conversion factor
74 0.1
2 100
1 10
0 1
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
Data type:
Data type shows the type and length of the telegram.
Data type
Description
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Text string
VLT
®
6000 HVAC Series
212 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
