Danfoss VLT 6000 HVAC Series User Manual

PNU Parameter Factory setting Range Changes 4-Setup
Conver-
sion
Data
# description during operation index type
500 Protocol FC protocol Yes Yes 0 5
501 Address 1 Depends on par. 500 Yes No 0 6
502 Baudrate 9600 Baud Yes No 0 5
503 Coasting Logic or Yes Yes 0 5
504 DC-brake Logic or Yes Yes 0 5
505 Start Logic or Yes Yes 0 5
506 Direction of rotation Logic or Yes Yes 0 5
507 Selection of Setup Logic or Yes Yes 0 5
508 Selection of preset reference Logic or Yes Yes 0 5
509 Data read-out: Reference % No No -1 3
510 Data read-out: Reference unit No No -3 4
511 Data read-out: Feedback No No -3 4
512 Data read-out: Frequency No No -1 6
513 User defined read-out No No -2 7
514 Data read-out: Current No No -2 7
515 Data read-out: Power, kW No No 1 7
516 Data read-out: Power, HP No No -2 7
517 Data read-out: Motor voltage No No -1 6
518 Data read-out: DC link voltage No No 0 6
519 Data read-out: Motor temp. No No 0 5
520 Data read-out: VLT temp. No No 0 5
521 Data read-out: Digital input No No 0 5
522 Data read-out: Terminal 53,
analogue input
No No -1 3
523 Data read-out: Terminal 54,
analogue input
No No -1 3
524 Data read-out: Terminal 60,
analogue input
No No -4 3
525 Data read-out: Pulse reference No No -1 7
526 Data read-out: External reference % No No -1 3
527 Data read-out: Status word, hex No No 0 6
528 Data read-out: Heat sink temperature No No 0 5
529 Data read-out: Alarm word, hex No No 0 7
530 Data read-out: Control word, hex No No 0 6
531 Data read-out: Warning word, hex No No 0 7
532 Data read-out: Extended status word, hex No No 0 7
533 Display text 1 No No 0 9
534 Display text 2 No No 0 9
535 Busfeedback 1 No No 0 3
536 Busfeedback 2 No No 0 3
537 Data read-out: Relay status No No 0 5
538 Data read-out: Warning word 2 No No 0 7
555 Bus time interval 1 sec. 1 - 99 sec. Yes Yes 0 5
556 Bus time interval function OFF Yes Yes 0 5
560 N2 override release time OFF 1 - 65534 sec. Yes No 0 6
565 FLN Bus time interval 60 sec. 1 - 65534 sec. Yes Yes 0 6
566 FLN Bus time interval function OFF Yes Yes 0 5
570 Modbus parity and message framing No parity 1 stopbit Yes Yes 0 5
571 Modbus communications timeout 100 ms 10 - 2000 ms Yes Yes -3 6
VLT
®
6000 HVAC Series
MG.61.B5.02 - VLT
®
is a registered Danfoss trademark 215
All about VLT 6000
HVAC
