Danfoss VLT 6000 HVAC Series

200-240 V
Typecode
Position in string
T2
9-10
C00
11-13
B20
11-13
C20
11-13
CN1
11-13
C54
11-13
ST
14-15
SL
14-15
R0
16-17
R1
16-17
R3
16-17
1.1 kW/1.5 HP 6002 X X X X X
1.5 kW/2.0 HP 6003 X X X X X
2.2 kW/3.0 HP 6004 X X X X X
3.0 kW/4.0 HP 6005 X X X X X
4.0 kW/5.0 HP 6006 X X X X X X
5.5 kW/7.5 HP 6008 X X X X X X
7.5 kW/10 HP 6011 X X X X X X
11 kW/15 HP 6016 X X X X X X
15 kW/20 HP 6022 X X X X X X
18.5 kW/25 HP 6027 X X X X X X
22 kW/30 HP 6032 X X X X X X
30 kW/40 HP 6042 X X X X X X
37 kW/50 HP 6052 X X X X X X
45 kW/60 HP 6062 X XXX XX
380-460 V
Typecode
Position in string
T4
9-10
C00
11-13
B20
11-1
3
C20
11-1
3
CN1
11-1
3
C54
11-13
ST
14-1
5
SL
14-1
5
EX
14-15
DX
14-1
5
PS
14-1
5
PD
14-15
PF
14-1
5
R0
16-1
7
R1
16-17
R3
16-1
7
1.1 kW/1.5 HP 6002 X X X X X
1.5 kW/2.0 HP 6003 X X X X X
2.2 kW/3.0 HP 6004 X X X X X
3.0 kW/4.0 HP 6005 X X X X X
4.0 kW/5.0 HP 6006 X X X X X
5.5 kW/7.5 HP 6008 X X X X X
7.5 kW/10 HP 6011 X X X X X
11 kW/15 HP 6016 X X X X X X
15 kW/20 HP 6022 X X X X X X
18.5 kW/25 HP 6027 X X X X X X
22 kW/30 HP 6032 X X X X X X
30 kW/40 HP 6042 X X X X X X
37 kW/50 HP 6052 X X X X X X
45 kW/60 HP 6062 X X X X X X
55 kW/75 HP 6072 X X X X X X
75 kW/100 HP 6102 X X X X X X
90 kW/125 HP 6122 X X X X X X
110 kW/150 HP 6152 X X X X X X X X X X X
132 kW/200 HP 6172 X X X X X X X X X X X
160 kW/250 HP 6222 X X X X X X X X X X X
200 kW/300 HP 6272 X X X X X X X X X X X
250 kW/350 HP 6352 X X X X X X X X X X X
315 kW/450 HP 6402 X X X X X X X X X X X
355 kW/500 HP 6502 X X X X X X X X X X X
400 kW/550 HP 6552 X X X X X X X X X X X
450 kW/600 HP 6602 X XXX XXXXXXX
Voltage
T2: 200-240 VAC
T4: 380-460 VAC
Enclosure
C00: Compact IP 00
B20: Bookstyle IP 20
C20: Compact IP 20
CN1: Compact NEMA 1
C54: Compact IP 54
Hardware variant
ST: Standard
SL: Standard with DC terminals
EX: Extended with 24 V supply and DC terminals
DX: Extended with 24 V supply, DC terminals, discon-
nect and fuse
PS: Standard with 24 V supply
PD: Standard with 24 V supply, fuse and disconnect
PF: Standard with 24 V supply and fuse
RFI filter
R0: Without filter
R1: Class A1 filter
R3: Class A1 and B filter
NB!
NEMA 1 exceeds IP 20
