440-480V, 60Hz
I
AHF,N
Typical Motor Used
[HP]
Danfoss ordering number VLT 6000
AHF 005 AHF 010
19 A 10, 15 175G6612 175G6634 6011, 6016
26 A 20 175G6613 175G6635 6022
35 A 25, 30 175G6614 175G6636 6027, 6032
43 A 40 175G6615 175G6637 6042
72 A 50, 60 175G6616 175G6638 6052, 6062
101 A 75 175G6617 175G6639 6072
144 A 100, 125 175G6618 175G6640 6102, 6122
180 A 150 175G6619 175G6641 6152
217 A 200 175G6620 175G6642 6172
289 A 250 175G6621 175G6643 6222
324 A 300 175F6689 175G6692 6272
370 A 350 175G6690 175G6693 6352
Higher ratings can be achieved by paralleling the filter units
506 A
450 217 A and 289 A units 6402
578 A 500 Two 289 A units 6502
578 A 550 Two 289 A units 6552
648 A 600 Two 324 A units 6602
Please note that the matching of the Danfoss frequen-
cy converter and filter is pre-calculated based on
400V/480V and assuming typical motor load (4 pole)
and 110 % torque. For other combinations, please
consult MG.80.BX.YY.
VLT
®
6000 HVAC Series
42 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
