Danfoss VLT 6000 HVAC Series User Manual

Mechanical dimensions
All the below listed measurements are in mm.
VLT Type
A B C a b aa/bb Type
IP 00 525 - 600 V
6102 - 6172 1046 408
373
1)
1001 304 225 J
6222 - 6402 1327 408
373
1)
1282 304 225 J
6502 - 6652 1547 585
494
1)
1502 304 225 J
IP 20/NEMA 1 525 - 600 V
6002 - 6011 395 220 200 384 200 100 C
6016 - 6027 560 242 260 540 200 200 D
6032 - 6042 700 242 260 680 200 200 D
6052 - 6072 800 308 296 780 270 200 D
6102 - 6172 1208 420
373
1)
1154 304 225 J
6222 - 6402 1588 420
373
1)
1535 304 225 J
6502 - 6652 2000 600
494
1)
- - 225 H
IP 54 525 - 600 V
6102 - 6172
1208 420
373
1)
1154 304 225 J
6222 - 6402 1588 420
373
1)
1535 304 225 J
6502 - 6652 2000 600
494
1)
- - 225 H
aa: Minimum space above enclosure
bb: Minimum space below enclosure
1) With disconnect add 44 mm.
VLT
®
6000 HVAC Series
62 MG.61.B5.02 - VLT
®
is a registered Danfoss trademark
