Danfoss VLT AHF 005

X1 Mains 35 mm
2
X2 Drive 35 mm
2
A/B Temperature 2.5 mm
2
X3/X4 Capacitor disconnect 16 mm
2
353 mm [13.9 in]
378 mm [14.9 in]
PE M8
624 mm [24.6 in]
240 mm [9.4 in]
157 mm [6.2 in]
9 mm [0.4 in]
157 mm [6.2 in]
624 mm ± 3 mm [24.6 in ± 0.10 in]
577 mm [22.7 in]
9 mm [0.4 in]
9 mm [0.4 in]
261 mm ± 3 mm [10.3 in ± 0.12 in]
330 mm ± 3 mm [13.0 in ± 0.12 in]
X1.1 X1.2
X1.3 X2.1
X2.2
X2.3
A B
X3.1
X3.2
X3.3
X4.1
X4.2 X4.3
130BD439.11
Illustration 7.123 IP00 X4
Specications
VLT
®
Advanced Harmonic Filter AHF 005/AHF 010
