8.1 Selection Tables
8.1.1 Capacitor Kits
Items supplied, capacitor kits
The spare part capacitor kits are complete kits including cabling and accessories for replacement.
The spare part capacitor kits support the following lters:
•
VLT
®
Advanced Harmonic Filter AHF 005 IP00.
•
VLT
®
Advanced Harmonic Filter AHF 005 IP20.
•
VLT
®
Advanced Harmonic Filter AHF 010 IP00.
•
VLT
®
Advanced Harmonic Filter AHF 010 IP20.
380–415 V, 50 Hz Capacitor kit
Current rating
Ordering number Description
[A]
10 175U0134 Capacitor bank AHF DA/B 400V-50Hz-010A
14 175U0135 Capacitor bank AHF DA/B 400V-50Hz-014A
22 175U0136 Capacitor Bank AHF DA/B 400V-50Hz-022A
29 175U0137 Capacitor Bank AHF DA/B 400V-50Hz-029A
34 175U0138 Capacitor Bank AHF DA/B 400V-50Hz-034A
40 175U0139 Capacitor Bank AHF DA/B 400V-50Hz-040A
55 175U0140 Capacitor Bank AHF DA/B 400V-50Hz-055A
66 175U0141 Capacitor Bank AHF DA/B 400V-50Hz-066A
82 175U0142 Capacitor Bank AHF DA/B 400V-50Hz-082A
96 175U0143 Capacitor Bank AHF DA/B 400V-50Hz-096A
133 175U0144 Capacitor Bank AHF DA/B 400V-50Hz-133A
171 175U0145 Capacitor Bank AHF DA/B 400V-50Hz-171A
204 175U0146 Capacitor Bank AHF DA/B 400V-50Hz-204A
251 175U0147 Capacitor Bank AHF DA/B 400V-50Hz-251A
304 175U0148 Capacitor Bank AHF DA/B 400V-50Hz-304A
325 175U0149 Capacitor Bank AHF DA/B 400V-50Hz-325A
381 175U0150 Capacitor Bank AHF DA/B 400V-50Hz-381A
480 175U0151 Capacitor Bank AHF DA/B 400V-50Hz-480A
Table 8.1 Capacitor Kits, 380–415 V, 50 Hz
Spare Parts
VLT
®
Advanced Harmonic Filter AHF 005/AHF 010
