Danfoss VLT AHF 005

500–
690 V
50 Hz
Fan Fan fence Fan transformer
Current
rating
[A]
Ordering
number
Quantity
required
Description
Ordering
number
Quantity
required
Description
Ordering
number
Quantity
required
Description
395 175U0266 2
AHF2 Fan
600–690 V
175U0323 2
AHF2 Fan fence
size 30
175U0269 2
Transformer for
AHF2
600 V/690–230 V
Table 8.15 Fan Kits and Accessories, 500–690 V, 50 Hz
8.1.4 Fuses
Items supplied, fuse kits and accessories
Fan fuses: The spare fuse kits contain 10 fuses.
Fuse holder: 1 item.
Cover for fuse holder: 1 item.
The spare part fuse kits support the following lters:
•
VLT
®
Advanced Harmonic Filter AHF 005 IP20.
•
VLT
®
Advanced Harmonic Filter AHF 010 IP20.
380–
415 V
50 Hz
380–
415 V
60 Hz
440–
480 V
60 Hz
600 V
60 Hz
500–
690 V
50 Hz
Fuse Fuse holder Fuse cover
Current rating
[A]
Ordering
number
Description
Ordering
number
Description
Ordering
number
Description
10
1)
10 10 – – – – – – – –
14 14 14 15 15
175U0114
AHF2
Fuse for fan
380–690 V
2 A
175U0115
AHF2
Fuse holder
380–690 V
175U0117
AHF2
Cover for fuse holder
380–690 V
22 22 19 20 20
29 29 25 24 24
34 34 31 29 29
40 40 36 36 36
55 55 48 50 50
66 66 60 58 58
82 82 73 77 77
96 96 95 87 87
133 133 118 109 109
171 171 154 128 128
204 204 183 155 155
251 251 231 197 197
304 304 291 240 240
325 325 355 296 296
381 381 380 366 366
480 480 436 395 395
Table 8.16 Fuse Kits and Accessories
1) 10 A version is cooled by natural convections.
